The versatile WSC-R unit is Ireland's number one meter box and is designed to securely house water meters and a wide range of control and monitoring equipment including pressure reducing valves and radio transponders for data logging.

The WSC-R Customer Access box provides the facility for the customer to access the stop-valve at lid level with a unique key and comes complete with secure locking ductile-iron lid.

It is available with a fixed body for all standard depths or with screw-down height adjustment for onsite adaptability. A range of locking or snap-shut, cast-iron or plastic lids are available.

This rugged unit is supplied ready to install and provides the key to effective management of water supply systems

The WSC-R Standard is available with locking or non-locking lid and comes complete with stopcock, quick release expansion joint, insulation pad and 3/4" MBSP box outlets.

The WSC-R Customer Access box provides the facility for the customer to access the stop-valve at lid level with a unique key and comes complete with a secure, locking ductile iron lid.

The WSC-R Telescopic box offers greater on-site adaptability with screw-down height adjustment to suit different service pipe depths and comes complete with snap-shut plastic lid.

Stocks kept in IPL ensures availablity at short notice.

Technical Features

LOCKING DUCTILE IRON LID ZINC-COATED DUCTILE IRON for positive corrosion protection CELTIC IRISH DESIGN with high visibility silver finish
(*snap-shut plastic lid available with WSC-R Telescopic)
SECURE SCREW LOCK SCREW OPERATION for easy opening & closing
DUCTILE IRON SUPPORT COLLAR SINGLE CASTING with increased strength & weight loading
FROST PROTECTION PAD EXPANDED POLYETHYLENE FOAM
CUSTOMER ACCESS SPINDLE* *CUSTOMER ACCESS TO STOP-VALVE at lid level available with WSC-R CUSTOMER ACCESS only
GUARD TUBE uPVC SINGLE WALL high strength tube
CHOICE OF METERS IN-LINE DESIGN for range of meters & control equipment
EXPANSION CONNECTION BRONZE EXPANSION CONNECTION & HAND WHEEL for easy installation of equipment by hand
BRONZE INLET & OUTLET PIECES NON-RETURN VALVE & PUSH FIT CONNECTORS
available CONNECTORS shown suit both Irish 1/2” Heavy Gauge and 20mm Metric Blue pipe
DUCTILE IRON COLLAR ZINC-COATED for positive corrosion protection
POLYPROPYLENE BASE High Visibility White Finish
