Product Overview

The i-glo White Line Delineator Strip from IPL group is a specialised safety feature designed to clearly separate pedestrian and cyclist zones on shared pathways. Manufactured to precise Department for Transport specifications, this 1-meter long x 150mm wide delineator features a distinctive white exterior with an illuminated green central insert that remains visible day and night. Its carefully engineered 20mm height with 23° sloping sides and a 50mm flat top creates the perfect balance between detectability for visually impaired users and traversability for those with mobility aids. Fully compliant with Traffic Signs Regulations and General Directions (TSRGD), this 3.6kg unit provides a continuous tactile and visual guide that significantly improves safety and navigation confidence for all pathway users.

Key Benefits

• Clear Path Segregation: Precisely separates pedestrian and cyclist zones on shared pathways, enhancing safety for all users.
• 24-Hour Visibility: Features an illuminated green central insert that remains visible day and night, providing continuous guidance.
• Optimal Accessibility: Engineered with a 20mm height, 23° sloping sides, and a 50mm flat top for a perfect balance between detectability for visually impaired users and traversability for mobility aids.
• Regulatory Compliance: Fully compliant with Department for Transport specifications and Traffic Signs Regulations and General Directions (TSRGD).
• Durable Construction: Robust 3.6kg unit designed to withstand outdoor exposure and regular traffic without compromising performance.
• High Safety Compliance: Achieves a Pendulum Test Value (PTV) of 68, indicating a low slip risk (less than 1 in 1 million probability), significantly exceeding the HSE recommended minimum of 36 PTV.

Applications

The White Line Delineator Strip is primarily used for enhancing safety and clarity on shared pathways, suitable for:

• Clearly separating pedestrian and cyclist zones.
• Guiding all pathway users, especially the visually impaired.
• Improving navigation confidence in shared public spaces.

Features & Construction

• Manufactured to precise Department for Transport specifications.
• Distinctive white exterior with an illuminated green central insert.
• Carefully engineered 20mm height with 23° sloping sides and a 50mm flat top.
• Continuous tactile and visual guide.
• Size: 1000mm x 150mm.
• Vertical Base Height: 6mm.

Customisation Options

• (No specific customisation options are explicitly mentioned in the provided datasheet beyond its inherent design and colour.)

Technical Specifications

Specification	Value
Size	1000mm x 150mm
Height	20mm
Colour	White (with illuminated green central insert)
Weight	3.6kg
Angular Slope	23 degrees
Vertical Base Height	6mm
Pendulum Test Value (PTV)	68 PTV (Low Slip Risk, Pass)
Compliance	Department for Transport specifications, Traffic Signs Regulations and General Directions (TSRGD)

Installation & Maintenance

• Installation: Further information and installation requirements are available from IPL group.
• Maintenance: Durable construction (3.6kg) ensures it withstands outdoor exposure and regular traffic without compromising performance. Its continuous visibility day and night reduces maintenance needs for external lighting.
