Product Overview

The System 2000 - Flange for PE and PVC pipes is designed to provide a high-tensile restraint connection for both PE and PVC pipelines. This flange features a push socket for secure pipe insertion and is sized according to EN 1092-2 standards, with drilling compliant with EN 1092-2 | PN 10 standard, and PN 16 for DN 200 to DN 600. It includes an integrated flange seal made of elastomer, ensuring a reliable seal. This component is part of the System 2000 range, known for its robust and user-friendly fittings for demanding infrastructure applications.

Key Benefits

• Provides high-tensile restraint connection for PE and PVC pipes.
• Flange sized and drilled in accordance with EN 1092-2 standards.
• Integrated flange seal made of elastomer for reliable sealing.
• Robust construction ensures durability and long service life.
• Easy pipe insertion into the socket.

Applications

• Connecting PE and PVC pipes in water distribution and other pipeline networks.
• Applications requiring restraint connections.

Features & Construction

• Body: Made of ductile iron, epoxy powder coated.
• Lock ring: Made of ductile iron, epoxy powder coated.
• Grip ring: Made of brass (bronze from DN 300).
• Hexagonal bolts: Made of stainless steel.
• Lip seal ring: Made of elastomer.
• Spacer bushes: Made of PE.
• Integrated flange seal: Made of elastomer.

Technical Specifications

System 2000 Flanges for PE and PVC pipes are available across a wide range of nominal diameters (DN). Pressure ratings include PN 16 (for DN 50-DN 150) and PN 10 (for DN 200-DN 600), with PN 16 for DN 200-DN 600 available on request. Flange connection dimensions comply with EN 1092-2.

DN (mm)	Ø pipe A (mm)	OD (mm)	L (mm)	Weight (kg)
50	63	165	90	3.7
60	63	175	90	3.8
60	75	175	92	4.0
65	63	185	90	4.3
65	75	185	92	4.6
80	63	200	90	4.7
80	75	200	92	4.8
80	90	200	95	5.5
100	90	220	95	6.8
100	110	220	95	6.3
100	125	220	97	6.6
125	110	250	95	7.7
125	125	250	97	7.8
125	140	250	103	10.3
125	160	250	145	11.5
150	140	285	103	11.3
150	160	285	115	10.5
150	180	285	125	12.5
200	200	340	135	16.8
200	225	340	138	18.0
200	250	340	225	27.0
250	250	400	155	28.4
250	280	400	158	29.0
300	315	455	184	43.0
300	355	455	277	63.0
400	400	565	242	76.5
400	450	565	302	84.0
500	500	715	365	144.0
500	560	715	450	167.0
600	630	840	459	256.0

Installation & Maintenance

• Pipe installation involves chamfering the pipe and using lubricant (not oil).
• Push the pipe to the end of the socket.
• Tighten the lock ring bolts crosswise until the lock ring is tight on bushes. Maximum tightening torque for the lock ring should be observed.
• For PE pipes with thin walls (SDR 21) and low internal pressure, using a support liner is recommended.
• For dismantling, loosen and remove lock ring bolts, then twist and withdraw the pipe.
