Product Overview

The STELLED Illuminated Bollard, crafted from 316 stainless steel by IPL group, boasts a sleek design suitable for garden seating areas, driveways, and larger commercial or public spaces like car parks and golf courses. Its unique head design accommodates a large 20W LED corn bulb, ensuring high lumen output and making it compatible with most PIR and Photocell systems. This is the most recent development in Road Signaling, allowing for effective signaling and alerting in areas of reduced visibility, such as walkways, points of divergence, and tight curves. While offering robust illumination, it is not a product intended for the axle of the track due to the rigidity of its upper part.

Key Benefits

• High-Grade 316 Stainless Steel Construction: Ensures durability and resistance to corrosion, making it ideal for outdoor environments.
• Sleek Modern Design: Enhances both residential and commercial spaces with its aesthetic appeal, including gardens, driveways, and public areas.
• Superior Illumination: Features a 20W LED Corn Bulb providing high lumen output (1800 lm - 2300 lm) for superior illumination, increasing visibility and safety. Offers 360° visibility with 8 white spotlights and flashing light capability.
• Smart Lighting Control: Compatible with PIR and Photocell systems for flexible lighting control and easy integration with existing systems.
• Energy-Efficient & Cost-Effective: Reduces electricity consumption, leading to lower operational costs, with an average life of up to 30,000 hours for the LED bulb.
• Advanced Bulb Technology: Utilises 72 high-quality Epistar 2835 LEDs (or San'an 2835 SMD) for optimum results, emitting light in all directions, protected by sectioned polycarbonate covers.

Applications

The STELLED Illuminated Bollard is suitable for a wide range of outdoor illumination and signaling applications:

• Garden seating areas and driveways.
• Larger commercial or public spaces like car parks and golf courses.
• Walkways, points of divergence, tight curves, and other areas of reduced visibility for signaling and alerting.
• Residential and commercial lighting projects requiring robust and aesthetic illumination.

Features & Construction

• Material: 3mm 316L Stainless-Steel & Polycarbonate.
• Sleek modern design with a unique head design.
• Top made with "Bulletproof PC".
• Integrated LED illumination with 8 white spotlights.
• Flashing light and 360° Visibility.
• Bulb Holder: ES / E27.
• Max Wattage: 60W.
• Voltage: 220-240V (Bollard); 95-265V (Bulb).
• IP Rating: IP64 (Bulb).
• Average Life: up to 30,000 hours (Bulb).

Customisation Options

• Height Options: 800mm | 1000mm.
• Fixing Options: Internal Surface Mount | Root-Fixed.
• Choice of Colour Temperatures for bulb: Daylight White 6500K | Warm White 3000K.

Technical Specifications

Specification	Value
Material	3mm 316L Stainless-Steel & Polycarbonate
Diameter	120mm
Height Options (above ground)	800mm | 1000mm
Fixing Options	Internal Surface Mount | Root-Fixed
Bulb Holder	ES / E27
Max Wattage (Bollard)	60W
Voltage	220-240V
LED Bulb Wattage	20W
Lumen Output	1800 lm, 2300 lm (Nominal: 2100 lm/2250 lm)
Colour Temperatures	Daylight White 6500K / 6000K-7000K | Warm White 3000K / 2700K-3300K
Start-up Time	Instant
Average Life (Bulb)	Up to 30,000 hours
IP Rating (Bulb)	IP64
Dimensions (Bulb)	185mm (L) x 65mm (W)

Installation & Maintenance

• Installation: Suitable for ground fixed installation, with options for Internal Surface Mount or Root-Fixed. Compatible with most PIR and Photocell systems for easy integration. Further information and installation requirements are available from IPL group.
• Maintenance: High-grade 316 Stainless Steel ensures durability and resistance to corrosion, minimizing maintenance. The energy-efficient LED bulb has a long average life, reducing replacement frequency.
