Product Overview

The SITRANS LR550 is a continuous radar level transmitter featuring a polymeric horn antenna. It is capable of continuously monitoring solids or liquids up to a range of 120 metres (394 ft). Its lightweight design makes it suitable for open-air applications and for inventory measurement in silos and vessels, as well as for monitoring river levels.

Key Benefits

• Continuous, non-contact measurement for a wide range of applications.
• Suitable for both solids and liquids.
• Features a long measuring range of up to 120 metres.
• The lightweight design is suitable for use in open air.

Applications

The SITRANS LR550 is suitable for a range of applications, including:

• Inventory measurement of basic materials in silos and vessels.
• River level monitoring.
• General open-air applications.

Features & Construction

• Polymeric horn antenna.
• Communication via 4 to 20 mA, HART.
• Flange material is PP-GF30.
• Wetted materials include PP, FKM, or EPDM.
• Wall and ceiling bracket is made from 316/316L stainless steel.
• Features a single compartment enclosure.
• Electrical connection options include M20 or NPT.

Technical Specifications

Characteristic	Value
Recommended Measuring Range	120 m (394 ft)
Beam Angle	3°
Process Temperature	-40 to +80°C (-40 to +176°F)
Process Pressure	2 bar max (29.0 psi)

Installation

• The device can be installed using either a ceiling or wall mounting.
• Nozzle mounting has specific restrictions depending on the nozzle diameter and height.
• For nozzles with an 80 mm (3") diameter, the height must be no more than 400 mm (15.8").
• For nozzles with a 100 mm (4") diameter, the height must be no more than 500 mm (19.7").
• For nozzles with a 150 mm (6") diameter, the height must be no more than 800 mm (31.5").
