Product Overview

Controlled and reliable measurements are at the heart of Kuntze Krypton® systems. The Krypton® Multi measuring system provides a comprehensive solution for disinfectant measurement, including the instrument, software, sensors, flow cell, and cables, all tailored to customer needs.

The Krypton® Multi is a versatile measurement system for disinfectant, pH, and temperature. Options are available to expand its capabilities with ORP/redox, conductivity, or an additional disinfectant measurement. The Krypton® Multi system is delivered fully assembled and ready for immediate use.

Krypton® Multi’s water measurement process can be controlled at any time, from any location, on any device via Kuntze‘s Cloud Connect® service. All Kuntze products are manufactured by Kuntze Instruments in Hartha, Germany.

Applications

• Process Water
• Disinfection
• Drinking Water
• Food & Beverage

Parameters

• Disinfectants:
  • Free Chlorine, Chlorine Dioxide, Total Chlorine: up to 1000 µg/l, 5.00 / 10.00 / 20.00 mg/l
  • Ozone: up to 1000 µg/l, up to 5.00 / 10.00 mg/l
  • Hydrogen peroxide: up to 30.00 mg/l
• Temperature: 0 to 50 °C (32 to 122 °F)
• pH: 0 to 14.00 pH
• Redox potential (optional): -1500 to +1500 mV
• 5th measuring input (optional): Conductivity: up to 100.0 mS/cm
• 6th measuring input (optional / DIS 2): Free Chlorine, Total Chlorine: up to 1000 µg/l, up to 5.00 / 10.00 / 20.00 mg/l
• Digital inputs: Flow control, external controller stop, 2x level control, activation 2nd or 3rd control parameter set

StabiFlow®

StabiFlow® is an assembly designed for precise measurement of disinfectants, providing:

• Constant flow of approx. 30 l/h
• Stable, precise, and reliable measurements
• Cost reduction due to increased life expectancy of the sensors

ASR®

ASR® is Kuntze's patented automatic sensor cleaning technology that:

• Keeps the electrode surfaces automatically clean and reduces maintenance efforts
• Is available for measurement of Free Chlorine, Chlorine Dioxide, Ozone, and Hydrogen Peroxide
• Offers cost reduction due to less maintenance
• Eliminates manual cleaning
• Requires no refill of chemical or physical agents
• Significantly reduces calibration demand
