Product Overview

The BRENT Strainer is a flanged device designed to mechanically remove suspended solids and debris from the flowing liquid using an internal screen. This action protects downstream equipment and maintains the integrity of the pipeline. The strainer is suitable for use with water and other neutral liquids, and is capable of withstanding a maximum working pressure of 16 bar.

Key Benefits


• Mechanically removes suspended solids and debris.

• Protects downstream equipment from damage.

• Suitable for water and other neutral liquids.

• Maximum Working Temperature of 70°.

• Coating and rubber parts are WRAS Certified.

Applications


• Flanged pipeline systems requiring the removal of solids and debris.

• Systems needing protection for sensitive downstream equipment.

Features & Construction

Design & Standards: Manufactured in accordance with flange connection part standard DIN28604-DIN28606, and face-to-face length standard DIN3202. Working Pressure: 16 bar.


• Filter Body: GJS500-7.

• Plug: SS304.

• Filter Mesh: SS304.

• Skeleton: GJS500-7.

• O ring: EPDM.

• Nuts: A2-70.

• Gasket: SS304.

• Filter Cover: Q235.

• Bolts: A2-70.

• Middle Head Seal Ring: EPDM.

Technical Specifications

BRENT Strainers are available in the following DN sizes, with corresponding face-to-face length (L in mm):



DN (mm)	L (mm)
50	230
80	300
100	300
150	400
200	504
250	580
300	610
