Hawle Knife Gate Valve No. 3600/3600EL
PN 10, PN16, DN50 - DN400

Resilient seated gate valve for many applications in for example sewage treatment plants, the paper industry, the mining industry, the chemical and animal feed stuff industries and for low viscosity fluids and dry products.

High corrosion resistance is ensured by the use of high grade stainless steel for the knife and spindle and epoxy powder coating for the grey cast iron body.

The Knife Gate Valve can be mounted either between two flanges in a pipeline or with an opposing flange at the end of a pipeline. The bore is clear and unobstructed.

The valve can be operated with a handwheel, a key, an extension spindle or by an electrically powered actuator. Please specify as required.

Hawle No. 3600 / 3600EL Technical Specifications

Dimensions DN 50 65 80 100 125 150 200 250 300 350 400
Working pressure PN 10 10 10 10 10 10 10 6 6 6 6
Flange k 125 145 160 180 210 240 295 350 400 460 515
  d2 19 19 19 19 19 23 23 23 23 23 28
Bolts Thread M 16 M 16 M 16 M 16 M 16 M 20 M 20 M 20 M 20 M 20 M 24
- Through bore holes Qty. 2 2 6 6 6 6 6 8 8 10 10
- Blind tapped holes Qty 4 4 4 4 4 4 4 8 8 12 12
  t Depth 9,5 11 10 13 14 14 14 14 19 19 26
Bolt length with washer Through bore holes 110 110 110 120 120 130 130 150 160 160 200
for standard flange EN 1092-2, PN 10 Blind tapped holes 34 35 35 36 38 38 38 40 48 48 56
Valve H 349 381 450 490 559 619 753 957 1081 1242 1353
  h 65 72 95 105 120 136 162 169 193 226 250
  H 1 284 309 355 385 439 483 591 788 888 1016 1103
  B 125 139 188 206 234 268 319 347 399 462 512
  L 43 46 46 52 56 56 60 68 78 78 102
  B 1 88 88 100 100 100 100 127 160 160 180 180
Spindle a 10,3 10,3 14,8 14,8 19,3 19,3 19,3 24,3 24,3 27,3 27,3
  c 20 20 30 30 38 38 38 48 48 48 48
  d 1 16 16 22 22 25 25 28 32 32 36 36
Knife s 6 6 8 8 8 8 10 12 12 15 15
Electric actuator Type     SA07.5 SA07.5 SA07.5 SA07.5 SA10.1 SA10.1 SA10.1 SA14.1 SA14.1
  H 2     739 779 852 912 1048 1256 1380 1584 1695
  H 3     569 609 682 742 878 1086 1210 1404 1514
  H 4     396 426 484 528 636 837 937 1068 1155
  B 2     273 273 273 273 287 279 279 318 318
  B 3     265 265 265 265 282 282 282 385 385
  B 4     250 250 250 250 256 256 256 325 325
  Open/close revolutions     8 10 13 15 20 21 25 29 34
  d 3     20 20 20 20 20 20 20 30 30
Weight kg No. 3600 6,3 7,0 11,0 14,0 17,0 22,0 33,0 73,0 99,0 140,0 180,0
  No. 3600EL     13,0 16,0 19,5 24,5 36,0 76,0 102,0 144,0 184,0
