The CLA-VAL ECO 32-27 is a flushing valve designed to Open/Close valves allowing smooth flushing of a pipeline or network. The user defines the Opening/Closing times.

Programming is time based only. Water velocity through the valve is controlled by adjusting cover mechanical opening control. The electronic controller e-Smart/L1 is programmed according to customer needs.

When opening time is reached valve opens automatically allow smooth flushing of the pipe line.

CLA-VAL ECO SERIES products include a CLA-VAL valve and battery powered autonomous electronic controller.

These controllers extend the traditional range of applications of CLA-VAL valves by adding TIME, FLOW or SWITCH controls.

CLA-VAL Eco 32-27 - Technical Specifications

Flanged(mm) DN50 DN65 DN80 DN100 DN125 DN150 DN200 DN250 DN300 DN350 DN400 DN450 DN500 DN600
L 230 290 310 350 400 480 600 730 850 980 1100 1200 1250 1450
F 145 170 170 235 295 295 400 510 600 712 712 712 900 900
H 195 225 230 305 365 375 460 547 695 821 821 900 1035 1035
H1(PN10) 82.5 93 100 110 125 142.5 170 200 227.5 252.5 282.5 325 370 430
H1 (PN16) 82.5 93 100 110 125 142.5 170 200 227.5 260 290 325 370 430
H1 (PN25) 82.5 93 100 117.5 135 150 180 212.5 242.5 277.5 310 335 370 430
Hm 255 295 300 390 470 480 585 700 875 1030 1030 1200 1310 1310
A 190 200 200 200 235 250 270 290 365 400 425 450 520 520
B 145 150 150 160 160 165 200 200 345 385 380 420 460 460
øC 45 60 60 60 60 80 80 80 80 80 80 80 - 120
Weight(Kg) 15 20 25 40 60 70 120 190 330 540 640 700 980 1080
