The BRENT universal pipe couplings are designed to easily and securely connect plain ended watermains. The flexibility and range allows connection to different pipe materials and outside diameters.

The BRENT couplings are fully epoxy coated on all surfaces and are fitted with stainless steel bolts. This is an inorganic protective metal coating with effective and world recognised corrosion resistance. The rubber rings are EPDM as standard.

Storage and fitting - Pipe fittings with rubber seals should be stored indoors or under cover, protected from direct sunlight. When fitting, ensure rubber seals are well lubricated on all surfaces.

Material Details
  • Body - Ductile Iron (GGG50)
  • End - Rings Ductile Iron (GGG50)
  • Gasket - EPDM
  • Bolts/Nuts - Stainless steel
  • DN 40-300
  • PN 10/16
  • Applications Steel, ductile iron, cast iron, asbestos cement, PVC
  • Max. axial offset of pipes 10mm
  • Tot. angular deflection ±6 Deg
  • Max Working Pressure 16 Bar
  • Max Working Temperature 70 Deg C
  • Brent Wide Range Coupling Technical Specifications

    DN (mm) Range 1 (mm)
    2” 59 - 73
    2½”  72 - 85
    3”  88 - 103
    4”  108 - 128
    5” 132 - 146
    5” 138 - 153
    6” 158 - 181
    7” 192 - 210
    8” 218 - 235
    8” 230 - 247
    9” 250 - 267
    10”  272 - 289
    12” 322 - 339
    12” 332 - 349
